22 11 011 Replacing left engine mount

WARNING: This page is about a different car, the 2018 BMW 330i and 2017 BMW 330i. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Secure the ENGINE IN INSTALLATION POSITION .
Remove front UNDERBODY PROTECTION .

Removal:

Loosen screws (1).

Remove engine mount (2).

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Installation note:

Rubber part (1) of engine mount must point to center of vehicle.

Courtesy of BMW OF NORTH AMERICA, INC.

Install engine mount (2).

Tighten down screws (1).

Tightening torque, refer to: 22 11 1AZ .

Courtesy of BMW OF NORTH AMERICA, INC.

Required follow-up work:

Remove the engine FASTENING .
Install front UNDERBODY PROTECTION .
