13 71... Removing intake port (N57 D30 O/T 1)

Unclip intake port (1) from the air duct at the front.

Detach the latch mechanism (2) in the intake filter housing.

Feed out intake port and remove.

Fig 1: Identifying Intake Port And Latch Mechanism

Courtesy of BMW OF NORTH AMERICA, INC.
