63 17 255 Removing and installing/replacing right fog light (LED technology)

IMPORTANT: Follow notes for HANDLING BULBS/LIGHT SOURCES (EXTERIOR LIGHTS) .

NOTE: The time value of this job item does not include adjustment of the fog lights!

Necessary preliminary tasks:

Release screws (1).

Tightening torque 63 17 1AZ .

Remove fog light (2) out of bumper panel (3) in direction of arrow.

Fig 1: Removing Fog Light Out Of Bumper Panel

Courtesy of BMW OF NORTH AMERICA, INC.

On replacement of fog light or bumper panel at front:
