65 12 051 Removing and installing/renewing central bass speaker - driver's/passenger's side- (under front seat)

Necessary preliminary work:

Release screws.

Remove cover (1).

Fig 1: Identifying Cover With Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Fold up the carpet (1) as shown.

Release screws.

Tightening torque 65 13 2AZ .

Unscrew nuts (2).

Remove central base support (3).

Fig 2: Identifying Central Base Support, Carpet And Nuts

Courtesy of BMW OF NORTH AMERICA, INC.
