51 23 110 Removing and installing/replacing left engine compartment lid lock

Necessary preliminary tasks:

Engine compartment lid catch with microswitch:

Detach plug connection (1) by twisting from catch carrier.

Unfasten plug connection (1) and disconnect.

Fig 1: Identifying Engine Compartment Lid Plug Connections Angle

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1).

Tightening torque 51 23 2AZ .

Remove engine compartment lid lock (2) downwards.

Fig 2: Identifying Engine Compartment Lid Lock And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Disengage Bowden cable (1) in direction of arrow from engine compartment lid lock (2).

Remove engine compartment lid catch.

Fig 3: Removing Bowden Cable From Engine Compartment Lid Lock

Courtesy of BMW OF NORTH AMERICA, INC.
