63 31 080 Removing and installing/replacing luggage compartment light

IMPORTANT: Follow notes for HANDLING LIGHT BULBS (INTERIOR LIGHTS) .

Removal:

On left side:

Lever luggage compartment light (1) out of trim panel (2) in direction of arrow.

Disconnect associated connector and remove luggage compartment light (1).

Fig 1: Removing Luggage Compartment Light From Trim Panel (Left)

Courtesy of BMW OF NORTH AMERICA, INC.

On right side:

Lever luggage compartment light (1) out of trim panel (2) in direction of arrow.

Disconnect associated connector and remove luggage compartment light (1).

Fig 2: Removing Luggage Compartment Light From Trim Panel (Right)

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

On left side:

Connect corresponding connector.

Insert luggage compartment light (1) into trim panel (2) in opposite direction to arrow.

Fig 3: Installing Luggage Compartment Light From Trim Panel (Left)

Courtesy of BMW OF NORTH AMERICA, INC.

On right side:

Connect corresponding connector.

Insert luggage compartment light (1) into trim panel (2) in opposite direction to arrow.

Fig 4: Installing Luggage Compartment Light From Trim Panel (Right)

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:
