PDC button in the center console operating unit
WARNING: This page is about a different car, the 2013 BMW X5, 2012 BMW X5, and 2011 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.
The PDC button switches the park distance control on or off (see Vehicle Owner's Handbook). When the PDC is switched on, the function LED lights up.
The PDC button is located in the center console operating unit. Electrically, the PDC button is connected to the controller (CON).
| Item | Description |
|---|---|
| 1 | Center console operating unit |
| 2 | DTC button |
| 3 | Driving dynamics control switch |
| 4 | Button for bumper camera |
| 5 | PDC button with function indicator light as well as button for rear view camera |
| 6 | 4-pin plug connection |
| 7 | 6-pin plug connection |
