13 62 585 Removing and installing/replacing the pressure sensor for the exhaust system (M57TU, M57T2, M57T2 SCR)

WARNING: This page is about a different car, the 2013 BMW X5, 2012 BMW X5, and 2011 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Make sure your hands are clean.
Avoid dirt contamination by lubricants and greases that contain oil.

Necessary preliminary work:

Read out DME fault memory.

Release plug connection (1) and pull off. Pull off hose (2).

Unlock locking tab (3) and remove pressure sensor (4) in direction of arrow.

Fig 1: Removing Pressure Sensor And Locking Tab

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Check the pressure hose (3). Replace hardened pressure hose.

Check connection on pressure pipe and pressure sensor for tightness.

A pressure hose which has been pulled off once must be secured with a 15 mm - 19 mm diameter screw clamp.

Tightening torque: 18 32 1AZ .

Fig 2: Identifying Pressure Hose

Courtesy of BMW OF NORTH AMERICA, INC.

Check function of DME.
