SI number

WARNING: This page is about a different car, the 2013 BMW X5, 2012 BMW X5, and 2011 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.

01 14 01 (766)

Fig 1: Identifying Holder (0493926)
G09969200Courtesy of BMW OF NORTH AMERICA, INC.

Consisting of:

  1. 0494227  Lever
  2. 0494228  Washer
    NOTE: Height 22.5 mm with hexagon screw
  3. 0494229  Needle
  4. 0494230  Socket WAF 46
    NOTE: (Socket, width across flats 27)
  5. 0494317  Washer
    NOTE: Height 10 mm with hexagon screw
