51 11 180 Removing and installing/replacing ornamental grille for bumper panel (center)
Necessary preliminary tasks:
- Remove FRONT BUMPER PANEL
Release the ornamental grille (1) at the latch mechanisms along the line (2).
Remove the ornamental grille (1).
Installation note:
Latch mechanisms must not be damaged or missing.
