54 12 115 Removing and installing glass slide/tilt sunroof panel
Installation note:
- Microencapsulated screws (Loctite) must be replaced and may not be reused
- Screw connection must be completed within 20 minutes (start of curing)
- Microencapsulated screws must not be retightened
- Clean thread of nut beforehand in event of repeated use
Necessary preliminary tasks:
- Remove both GAITERS
Release left and right screws (1).
Remove glass slide/tilt sunroof panel towards top.
Installation note:
Apply Loctite to screws.
Adjust GLASS SLIDE/TILT SUNROOF PANEL
Tightening torque: 54 12 01AZ .
Perform INITIALIZATION of glass slide/tilt sunroof
