Removing Engine Support In Front Of Bulkhead With Wheel Arch
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2023 BMW X2, 2022 BMW X2, 2021 BMW X2, 2020 BMW X2, and 2019 BMW X2. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
TECHNICAL INFORMATION
For additional information see: 41 00... Spot-weld bonding steel components
For additional information see: 41 00... Spot-weld bonding steel components
NOTE:
TECHNICAL INFORMATION
For additional information see: 41 00... Releasing bonded connections
For additional information see: 41 00... Releasing bonded connections
- Mark and carry out the separating cut (1) roughly, in accordance with the diagram.
- Release welded connections in areas (2).
- Open the spot-welded adhesive joints in the area (3) and remove the carrier support section.
- Remove adhesive residue in area (3).
- Release welded connections in areas (1).
- Release the welded connections in the areas (1) to (3).
- Open welded connections in area (2) for both outer panels.
- Mark and perform the separating cut (1) in accordance with the schematic diagram. While doing so, carry out the separating cut only on both outer panels.
- Open welded connections in area (2). While doing so, open the welded connections for both outer panels.
- Loosen welded connections in areas (3).
- Open welded connections in areas (1) and (2).
- Open welded connections in area (2) for both outer panels.
- Release the spot-welded adhesive joints in area (1).
- In areas (2), open the welded connections for both outer panels.
- Open welded connections in area (1).
- Mark and make the separating cut (1) as shown in the diagram.
- Open welded connections in areas (2) and (3).
In areas (3), open the welded connections for both outer panels.
- Remove engine support with wheel arch.
- Open welded connections in areas (1) and remove the residual part (2) of the engine support.
