Install the guide for the rear right bumper panel
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2023 BMW X2, 2022 BMW X2, 2021 BMW X2, 2020 BMW X2, and 2019 BMW X2. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Description is for left component only. Procedure on the right side is identical.
- Install the guide for the rear bumper panel
- Install the guide (3).
- Tighten the screws (1).
TIGHTENING TORQUE SPECIFICATIONS
| Guide for the bumper panel to body | ||
|---|---|---|
| Screw | Tightening torque | 4, 6 Nm |
| Nut | Tightening torque | 4, 6 Nm |
- Tighten nuts (2).
TIGHTENING TORQUE SPECIFICATIONS
| Guide for the bumper panel to body | ||
|---|---|---|
| Screw | Tightening torque | 4, 6 Nm |
| Nut | Tightening torque | 4, 6 Nm |
