Installing intake silencer housing

Prepare the intake filter housing

• Check the rubber mount (1)  for correct fit.

  Courtesy of BMW OF NORTH AMERICA, INC.

• Check rubber mounts (1)  for correct fit on the intake filter housing (2).

Courtesy of BMW OF NORTH AMERICA, INC.

• Thread in and install intake silencer housing (4)  into the intake port (5).

  The intake filter housing (4)  must engage audibly in the rubber mounts.

• Feed in the clean air pipe (3)  and install (arrow).

  The lock (2)  must audibly engage.

• Connect and lock the connector (1).

  The connector (1)  must engage audibly.

Courtesy of BMW OF NORTH AMERICA, INC.

Follow-up work

• Refer to INSTALLING THE DESIGN COVER .
