51 71 373 Removing and installing/replacing trailing link on spring strut dome

WARNING: This page does not describe the selected car, but rather 41 other vehicles, including the 2018 BMW 320i xDrive, 2018 BMW 320i, 2017 BMW 320i xDrive, 2017 BMW 320i, and 2016 BMW ActiveHybrid 3. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Driving without the trailing link is not permitted.
(risk of damage to the body).

Necessary preliminary tasks:

Remove COVER IN ENGINE COMPARTMENT on the left and right

Lever out covers (1) and release screws underneath.

Release screws (2) and remove trailing link (3).

Tightening torque: 51 61 1AZ

Installation note:

Replace screws and tighten to specified torque and then to angle of rotation.

Fig 1: Identifying Trailing Link Screws

Courtesy of BMW OF NORTH AMERICA, INC.
