51 41... Replacing speaker cover on left or right door trim panel

WARNING: This page is about a different car, the 2013 BMW Z4, 2012 BMW Z4, 2011 BMW Z4, 2010 BMW Z4, and 2009 BMW Z4. However, it is still accessible from the selected car via links, so may be relevant.

Partially fit special tool 00 9 317 as illustrated.

Carefully lever speaker cover (2) out of door trim panel (1).

IMPORTANT: Tape off working area. Risk of damage!

Fig 1: Fitting Special Tool (00 9 317) On Speaker Cover

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Guide (2) and catch along line (3) must not be damaged.

Insert guide (2) of speaker cover (1) correctly in opening (5) of door trim panel (4) and carefully engage speaker cover (1) on edge.

Fig 2: Identifying Guides Of Speaker Cover And Door Trim Panel

Courtesy of BMW OF NORTH AMERICA, INC.
