000224 Special tool board AM

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2015 BMW 740i, 2015 BMW 740Li xDrive, 2015 BMW 740Li, 2014 BMW 740i, and 2014 BMW 740Li xDrive. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Special Tool Board (000224)

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: (large special tool board 2 m x 1 m) This special tool board is used as the rear panel of basic and attachment frames and is the basis for large fixed or movable special tool boards.
