13 54 015 Removing and installing/sealing left throttle valve assembly (N63)

Necessary preliminary tasks:

Unlock plug (1) and remove.

Unfasten screws (2).

Tightening torque 13 54 1AZ .

Remove throttle valve assembly (3).

Installation:

Check plug connection (1) for coolant remnants. If necessary, clean plug connection (1) with compressed air.

Fig 1: Identifying Throttle Valve Assembly And Plug Connection

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Replace sealing ring (1) of throttle assembly (2).

Fig 2: Identifying Throttle Body Sealing Ring

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Check stored fault message.

clear fault memory.
