61 31 233 Removing and installing/renewing Lane Departure Warning engine electrical system (TLC actuator)
WARNING: This page does not describe the selected car, but rather 18 other vehicles, including the 2015 BMW Alpina B7L xDrive, 2015 BMW Alpina B7 xDrive, 2015 BMW 750i xDrive, 2015 BMW 750Li xDrive, and 2015 BMW 740Li xDrive. However, it is still accessible from the selected car via links, so may be relevant.
Necessary preliminary tasks
- Remove airbag unit
. See 32 34 030 REMOVING AND INSTALLING/REPLACING AIRBAG UNIT (SPORT STEERING WHEEL)
or 32 34 020 REMOVING AND INSTALLING/REPLACING AIRBAG UNIT
.
Remove lower steering wheel trim
Disconnect plug connection (1).
Release screws (2) and remove engine electrics (3).
Tightening torque 32 33 2AZ .
Installation note:
Replace screws (2).
Ensure correct cable routing.
Replacement from build date 03/2009:
Engine electrical system must be readjusted.
The service module "Adjustment actuator Lane Departure Warning" can be found at:
- Body
- Camera-based driver support systems
- Adjustment actuator Lane Departure Warning
