67 31 521 Removing and installing/replacing drive unit for seat height adjustment
WARNING: This page is about a different car, the 2013 BMW Z4, 2012 BMW Z4, 2011 BMW Z4, 2010 BMW Z4, and 2009 BMW Z4. However, it is still accessible from the selected car via links, so may be relevant.
Necessary preliminary tasks
- Remove FRONT SEAT
Unlock plug connections (1) and disconnect.
Unfasten screws (2).
Remove drive unit for seat height adjustment.
Installation:
Make sure drive shaft is correctly seated in gearbox.
