61 33 040 Removing and installing/replacing a fanfare horn

WARNING: This page is about a different car, the 2013 BMW Z4, 2012 BMW Z4, 2011 BMW Z4, 2010 BMW Z4, and 2009 BMW Z4. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove FRONT LEFT WHEEL ARCH COVER

Unlock plug connections (1) and disconnect.

Release screws (2) and remove fanfare horn (3) complete with holder.

Fig 1: Identifying Plug Connection And Fanfare Horn With Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

Slacken nut (1).

Remove holder (2) from air horn (3).

Fig 2: Identifying Holder Of Air Horn With Nut

Courtesy of BMW OF NORTH AMERICA, INC.
