17 51 000 Removing and installing/replacing intercooler (N54)

WARNING: This page is about a different car, the 2013 BMW Z4, 2012 BMW Z4, 2011 BMW Z4, 2010 BMW Z4, and 2009 BMW Z4. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks

Remove front UNDERBODY PROTECTION .

IMPORTANT: Coat sealing rings of quick-connect couplings with antiseize agent.

Pressure pipes cannot be fitted without antiseize agent.

If fitted: Release screws (1). Remove cover (2).

Fig 1: Identifying Screws And Cover

Courtesy of BMW OF NORTH AMERICA, INC.

Unfasten and detach charge-air hoses (1).

Unfasten screws (2).

Tightening torque 17 10 3AZ .

Remove intercooler (3) towards bottom.

Installation:

Charge-air hoses must audibly snap into place.

Coat sealing rings of charge-air hoses with antiseize agent.

Pressure pipes cannot be fitted without antiseize agent.

Fig 2: Identifying Charge Air Hoses, Screws And Intercooler

Courtesy of BMW OF NORTH AMERICA, INC.

Check charge-air duct for leaks.

Assemble engine.
