67 62 000 Removing and installing or replacing flat motor for front left or right power window regulator

Necessary preliminary tasks:

Unlock and disconnect the connector (1).

Release nuts at marked points.

Tightening torque: 51 33 2AZ .

Feed out flat motor (2).

Installation note:

Make sure flat motor (2) is correctly fitted in guide (3).

Fig 1: Flat Motor Nuts

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1).

Tightening torque: 51 33 1AZ .

Remove flat motor (2).

Fig 2: Flat Motor Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Make sure drive shaft (2) is correctly seated in mounting (1) at power windows (3).

Fig 3: Drive Shaft And Power Windows

Courtesy of BMW OF NORTH AMERICA, INC.

After installation:

An initialization must be carried out in order to activate anti-trap mechanism.

OBSERVE information on initializing power window regulator.
