51 16 063 Removing and installing/replacing interior mirror (overview)

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2016 BMW 328i xDrive, 2016 BMW 328d xDrive, 2015 BMW 328i xDrive, 2015 BMW 328d xDrive, and 2014 BMW 328i xDrive. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Interior mirrors with modified mirror base will be installed as of series launch F20 and for all subsequent series launches.
Observe new REPAIR INSTRUCTIONS !
Further introduction date:

F01, F02, F03, F06, F07, F10, F11, F12, F13, F18	07/2012
F25	03/2012

NOTE: If the information for the selected model is not required or not approved, the following message will be displayed when clicking on the "cross-reference": "No further information available for the currently selected vehicle context".

Distinguishing feature:

previous version, small mirror base (1) with round base plate on windscreen.
new version, large mirror base (2) with square base plate on windscreen.

NOTE: Dismantling of mirror cap is identical on both versions.

Fig 1: Mirror Base

Courtesy of BMW OF NORTH AMERICA, INC.

Version with mirror arm end cap:

Previous version.

Fig 2: Overview Of Interior Mirror (Version With Mirror Arm End Cap)
Courtesy of BMW OF NORTH AMERICA, INC.

Version with mirror arm end cap:

NEW VERSION .

Fig 3: Overview Of Interior Mirror (Version With Mirror Arm End Cap)
Courtesy of BMW OF NORTH AMERICA, INC.

Version with rain sensor:

Previous version.
NEW VERSION .

Fig 4: Overview Of Interior Mirror (Version With Rain Sensor)
Courtesy of BMW OF NORTH AMERICA, INC.

Version with Autobeam:

Previous version.
NEW VERSION .

Fig 5: Overview Of Interior Mirror (Version With Autobeam)
Courtesy of BMW OF NORTH AMERICA, INC.

Version with Toll interior mirror for Japan:

Previous version.
NEW VERSION .

Fig 6: Overview Of Interior Mirror (Version With Toll Interior Mirror For Japan)
Courtesy of BMW OF NORTH AMERICA, INC.
