51 45 195 Removing and installing/replacing instrument panel trim, bottom right

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2016 BMW 328i xDrive, 2016 BMW 328d xDrive, 2015 BMW 328i xDrive, 2015 BMW 328d xDrive, and 2014 BMW 328i xDrive. However, it is still accessible from the selected car via links, so may be relevant.

Unfasten screw connection (1).

NOTE: Version with knee airbag: Unscrew nuts (1).

Tightening torque: 51 45 9AZ .

Release trim panel (2) at clamps (3).

Feed out trim panel (2) in area (A) toward the bottom.

Lower trim panel (2) slightly and disconnect plug connections behind it.

Fig 1: Instrument Panel Trim And Clamps

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Feed in trim panel (2) in area (A) correctly behind the center console.

Clamps (3) must not be damaged.

Installation note:

Guides (1) must not be damaged or missing.

Feed guides (1) correctly into the corresponding holders on the vehicle.

Replacement (depending on version):

Remount FOOTWELL LIGHT (2) .

Remount power socket.

Fig 2: Footwell Light Guides And Clamps

Courtesy of BMW OF NORTH AMERICA, INC.
