SI number

WARNING: This page does not describe the selected car, but rather 50 other vehicles, including the 2016 BMW M5, 2016 BMW ActiveHybrid 5, 2016 BMW 550i xDrive, 2016 BMW 550i, and 2016 BMW 535i xDrive. However, it is still accessible from the selected car via links, so may be relevant.

01 04 07 (352)

Consisting of:

  1. 0496305  Adapter
    NOTE: Liquidation of existing inventory and then available only as a complete tool set 11 8 73 (83 30 0 496 107) - as of 19.04.12
  2. 0496306  Ring
    NOTE: (Sealing ring) For secure connection of test probe 11 0 222 and adapter 11 8 730/731.
    Fig 1: Identifying Adapter (0496107)
    G09965004Courtesy of BMW OF NORTH AMERICA, INC.
