SI number

WARNING: This page does not describe the selected car, but rather 50 other vehicles, including the 2016 BMW M5, 2016 BMW ActiveHybrid 5, 2016 BMW 550i xDrive, 2016 BMW 550i, and 2016 BMW 535i xDrive. However, it is still accessible from the selected car via links, so may be relevant.

01 14 01 (766)

Consisting of:

Fig 1: Identifying Holder (0493926)
G09965361Courtesy of BMW OF NORTH AMERICA, INC.
  1. 0494227  Lever
  2. 0494228  Washer
    NOTE: Height 22.5 mm with hexagon screw
  3. 0494229  Needle
  4. 0494230  Socket WAF 46
    NOTE: (Socket, width across flats 27)
  5. 0494317  Washer
    NOTE: Height 10 mm with hexagon screw
