54 10 160 Replacing left or right gaiter for glass slide/tilt sunroof
WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2017 BMW 550i GT xDrive, 2017 BMW 535i GT xDrive, 2017 BMW 535i GT, 2016 BMW 550i GT xDrive, and 2016 BMW 535i GT xDrive. However, it is still accessible from the selected car via links, so may be relevant.
Necessary preliminary work:
- Close glass slide/tilt sunroof
Carefully detach gaiter on the aluminum strip (1) from upper guide.
Unclip the support (2) for gaiter (rear) toward the passenger compartment.
Detach the support (2) in front (pull back and up).
Installation note:
If necessary, replace faulty gaiter.
Check that aluminum strip is firmly seated on guide.
