51 71 041 Removing and installing/replacing rear left or right wheel arch cover
WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2017 BMW 550i GT xDrive, 2017 BMW 535i GT xDrive, 2017 BMW 535i GT, 2016 BMW 550i GT xDrive, and 2016 BMW 535i GT xDrive. However, it is still accessible from the selected car via links, so may be relevant.
Necessary preliminary work:
- Remove REAR WHEEL
Release all marked screws (arrows).
Release screws (3).
Unscrew nuts (2).
Carefully feed out rear wheel arch cover (1) towards bottom.
Installation note:
Ensure wheel arch cover (1) is correctly seated.
Make sure all screws are installed in correct position.
Screws (3) are longer than remaining screws.
