61 31 233 Removing and installing/renewing Lane Departure Warning engine electrical system (TLC actuator)

WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2017 BMW 550i GT xDrive, 2017 BMW 535i GT xDrive, 2017 BMW 535i GT, 2016 BMW 550i GT xDrive, and 2016 BMW 535i GT xDrive. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove airbag unit. See AIRBAG UNIT or AIRBAG UNIT (WITH SPORT STEERING WHEEL) .

Remove lower steering wheel trim

Disconnect plug connection (1).

Release screws (2) and remove engine electrics (3).

Tightening torque 32 33 2AZ .

Installation note:

Replace screws (2).

Ensure correct cable routing.

Fig 1: Identifying Engine Electrics, Plug Connection And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement from build date 03/2009:

Engine electrical system must be readjusted.

The service module "Adjustment actuator Lane Departure Warning" can be found at:

Body
Camera-based driver support systems
Adjustment actuator Lane Departure Warning
