0491649 240155 Bush Mechanical tool

WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2017 BMW 550i GT xDrive, 2017 BMW 535i GT xDrive, 2017 BMW 535i GT, 2016 BMW 550i GT xDrive, and 2016 BMW 535i GT xDrive. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: (Spacer bush for spindle) Transmissions: A4S 310R
Fig 1: Identifying Bush (0491649)
G09869296Courtesy of BMW OF NORTH AMERICA, INC.
