0490464 004550 Awl Mechanical tool

WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2017 BMW 550i GT xDrive, 2017 BMW 535i GT xDrive, 2017 BMW 535i GT, 2016 BMW 550i GT xDrive, and 2016 BMW 535i GT xDrive. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: (Reamer adjustable 21.5...22.5 mm) For gudgeon pin bush in the connecting rod, discontinued since February 95
Fig 1: Identifying Awl (0490464)
G09868385Courtesy of BMW OF NORTH AMERICA, INC.
