0490061 000151 Base frame Mechanical tool

WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2017 BMW 550i GT xDrive, 2017 BMW 535i GT xDrive, 2017 BMW 535i GT, 2016 BMW 550i GT xDrive, and 2016 BMW 535i GT xDrive. However, it is still accessible from the selected car via links, so may be relevant.

Replaced by: 83300494897

NOTE: Length 4040 mm/height 2150 mm/depth 680 mm Replaced by 00 1 000 (0 494 897)
Fig 1: Identifying Base Frame (0490061)
G09868387Courtesy of BMW OF NORTH AMERICA, INC.
