Remove side marker

WARNING: This page is about a different car, the 2013 BMW 550i GT, 2012 BMW 550i GT, 2011 BMW 550i GT, and 2010 BMW 550i GT. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: The side marker (1) cannot be used again.

Carefully preheat side marker (1) in area (3) using hot air blower and use special tool 00 9 325 to release it from the bumper panel (2).

Fig 1: Removing Side Marker
G08422660Courtesy of BMW OF NORTH AMERICA, INC.
