130090 Sensor AM

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2015 BMW 740i, 2015 BMW 740Li xDrive, 2015 BMW 740Li, 2014 BMW 740i, and 2014 BMW 740Li xDrive. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: (Exhaust sensors with connecting hose) For raw gas removal at the exhaust manifold for checking the engine idle and exhaust content

Consisting of:

1= 0491218 Sensor

NOTE: (Exhaust probe, straight) Can be ordered as part of this special tool set (13 0 090 = 0491217).

2= 0491219 Sensor

NOTE: (Exhaust probe, offset) Can be ordered as part of this special tool set (13 0 090 = 0491217).

3= 0491220 Hose

NOTE: (Connecting hose with T-piece) Can be ordered as part of this special tool set (13 0 090 = 0491217).

4= 0491221 Adapter

NOTE: Between exhaust probe and exhaust manifold Can be ordered as part of this special tool set (13 0 090 = 0491217).

Fig 1: Identifying Sensor (130090)

Courtesy of BMW OF NORTH AMERICA, INC.
