67 62 020 Removing and installing/replacing flat motor for rear left or right power window lifter

Necessary preliminary tasks

• Remove rear left or right POWER WINDOW UNIT

Release screws (1) on power window unit (2).

Tightening torque 67 62 1AZ .

Fig 1: Identifying Screws On Power Window Unit

Courtesy of BMW OF NORTH AMERICA, INC.

Detach flat motor for power window unit (2) from power window unit (1).

Installation:

INITIALIZE POWER WINDOW .

Fig 2: Identifying Flat Motor With Power Window Unit

Courtesy of BMW OF NORTH AMERICA, INC.
