004550 Awl Mechanical tool

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2016 BMW 328i xDrive, 2016 BMW 328d xDrive, 2015 BMW 328i xDrive, 2015 BMW 328d xDrive, and 2014 BMW 328i xDrive. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: (Reamer adjustable 21.5...22.5 mm) For gudgeon pin bush in the connecting rod, discontinued since February 95
Fig 1: Identifying Awl (004550)
G10157291Courtesy of BMW OF NORTH AMERICA, INC.
