Version B

WARNING: This page is about a different car, the 2011 BMW 750xi, 2011 BMW 750Lxi, 2010 BMW 750xi, and 2010 BMW 750Lxi. However, it is still accessible from the selected car via links, so may be relevant.

Release headlight lens cover (1) at latch mechanisms (2) on both sides.

Remove headlight lens cover (1) from luggage compartment light (3) in direction of arrow.

Fig 1: Removing Headlight Lens Cover From Luggage Compartment Light

Courtesy of BMW OF NORTH AMERICA, INC.

Push bulb (1) out of socket with a suitable tool (e.g. screwdriver 3 mm blade) in direction of arrow and remove.

Installation note:

Note BULB TYPE .

Fig 2: Pushing Bulb Out Of Socket

Courtesy of BMW OF NORTH AMERICA, INC.

Check headlight lens cover (1) before fitting.

If necessary, carefully press together both side tabs a little in direction of arrow.

Fig 3: Checking Headlight Lens Cover

Courtesy of BMW OF NORTH AMERICA, INC.
