Applying adhesive

WARNING: This page is about a different car, the 2011 BMW 750xi, 2011 BMW 750Lxi, 2010 BMW 750xi, and 2010 BMW 750Lxi. However, it is still accessible from the selected car via links, so may be relevant.

Apply K2 adhesive in areas (1).

Guide nozzle at an angle of max. 60° along adhesive flange.

Cross-section of adhesive bead approx. 4 - 5 x 10 mm.

Apply a short reference bead at an appropriate point for later checking.

Fig 1: Identifying Roof Outer Skin Adhesive Residues

Courtesy of BMW OF NORTH AMERICA, INC.

Apply a little more adhesive K2 to nodes (1) of A- and C-pillars.

NOTE: Excess material is later used for spreading to side frame.

Fig 2: Identifying A And C-Pillars Adhesive K2 Applying Area

Courtesy of BMW OF NORTH AMERICA, INC.

Apply a little less adhesive (1) in area of holders (1).

Fig 3: Identifying Adhesive Area And Holders

Courtesy of BMW OF NORTH AMERICA, INC.
