0027 nut

WARNING: This page is about a different car, the 2011 BMW 750xi, 2011 BMW 750Lxi, 2010 BMW 750xi, and 2010 BMW 750Lxi. However, it is still accessible from the selected car via links, so may be relevant.

0496506 330027 nut MW

NOTE: (Nut M12x1.5 with thrust bearing) Only available as part of complete tool set 33 0 020 (83 30 0 496 494). [Not available separately]

Storage Location: C25

Fig 1: Identifying Nut (0496506)
G08465172Courtesy of BMW OF NORTH AMERICA, INC.
