24 00 054 Installing exchange transmission (GA8HP45Z) (N47)
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2016 BMW 328i xDrive, 2016 BMW 328d xDrive, 2015 BMW 328i xDrive, 2015 BMW 328d xDrive, and 2014 BMW 328i xDrive. However, it is still accessible from the selected car via links, so may be relevant.
IMPORTANT:
- Do not let skin come in contact with transmission oil and do not inhale fuel vapors.
- Wear protective gloves.
- Ensure adequate ventilation.
Drain automatic transmission fluid at oil drain plug.
Tightening torque 24 11 2AZ .
Recycling:
Catch and dispose of escaping transmission oil.
Observe country-specific waste disposal regulations.
IMPORTANT:
- Before installing replacement transmission, always flush TRANSMISSION FLUID COOLER TOGETHER WITH LINES .
- After completion of repair work, check TRANSMISSION OIL LEVEL .
- USE ONLY APPROVED TRANSMISSION OIL
.
Failure to comply with this requirement will result in serious damage to the automatic transmission!
Exchange transmissions come filled with oil
IMPORTANT:
After completion of repair work, program control transmission control unit.
Necessary preliminary tasks:
- Remove AUTOMATIC TRANSMISSION .
Release screw connection (1) of transfer box.
Tightening torque 27 10 1AZ .
Remount the transfer box (2).
Remount transportation retainer.
Remount all cable clips.
Remount all seal plugs.
Remount protective cap on output shaft.
IMPORTANT:
After removing transportation retainer, secure torque converter against slipping out.
Transmission identification:
- On type plate
