67 13 001 Replacing drive unit for electrically operated left or right exterior mirror

Necessary preliminary work

NOTE: Picture for example purposes only!

Release screw (1).

Remove drive for electrically operated exterior mirror (2) in direction of arrow from mirror housing (3).

Fig 1: Removing Electrically Operated Exterior Mirror From Mirror Housing

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Make sure pin housing (2) is correctly seated in connector housing (3).

Fit drive for electrically operated exterior mirror (1) so that mountings (4) slide in guides (5).

Fig 2: Identifying Electrically Operated Exterior Mirror, Pin Housing, Connector Housing, Mountings And Guides

Courtesy of BMW OF NORTH AMERICA, INC.
