61 31 116 Replacing rocker switch for side window operation (rear)

Necessary preliminary tasks

• Remove rear door trim panel. See 51 42 000 REMOVING AND INSTALLING LEFT OR RIGHT REAR DOOR TRIM PANEL .

Remove rocker switch (2) for side window operation on door trim panel (3) by applying pressure (A) to clips (1) in direction (B).

Installation:

Clips (1) must snap securely into door trim panel (3) (crash safety).

Fig 1: Applying Pressure On Door Trim Panel Mounting Clips

Courtesy of BMW OF NORTH AMERICA, INC.
