11 12 090 Removing and installing/renewing acoustic cover (N20)
Unlock and pull off vacuum connections (1 and 2) from vacuum accumulator.
Remove acoustic cover (1) in following steps:
- Unclip upwards in the front area.
- Pull out from rear rubber guide in direction of travel.
Installation note:
Insert acoustic cover (1) into existing rubber guides.
