Short exhaust manifold primary catalytic converter (condition OK)

Fig 1: Identifying Turbocharger Components (US Diesel, Left)
G09871933Courtesy of BMW OF NORTH AMERICA, INC.
Index Explanation
1 Fixture for control sensor
2 Catalytic converter
3 Mat for catalytic converter bearing
