25 11 071 Replacing Gearshift Lever Knob

WARNING: This page is about a different variant/trim than selected.

Pull installation frame of gaiter at the sides upwards out of center console.

IMPORTANT: Do not use a tool, as this would damage the installation frame or the center console.

Fig 1: Pulling Frame Of Gaiter At The Sides

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Do not twist knob during removal as this would cause the anti-twist lock in the knob to shear off.

Tug firmly to remove button.

Installation note:

Fit knob on gearshift lever, align and press on until it snaps noticeably into place.

Fig 2: Knob On Gearshift Lever

Courtesy of BMW OF NORTH AMERICA, INC.
