61 31 221 Removing and installing/replacing both multifunction steering wheel switches (M sports steering wheel)

Necessary preliminary tasks:

Release screws (1) on steering wheel.

Release screw (2) on rear side of steering wheel.

Remove design cover.

Installation note:

Make sure design cover is correctly seated.

Fig 1: Identifying Screws On Steering Wheel

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Steering wheel is shown removed for purposes of clarity.

Both multifunction steering wheel switches are connected to each other by wiring harness (2).

Release screws (1) for shift paddles.

Feed out wiring harness (2) and disconnect plug connection (3).

Installation note:

Make sure electrical wiring is correctly routed.

Fig 2: Disconnecting Plug Connection

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Steering wheel is shown removed for purposes of clarity.

Lift off shift paddles and release screws (1) on rear side of steering wheel.

Remove both multifunction steering wheel switches with wiring harness on front side of steering wheel.

Installation note:

Make sure electrical wiring is correctly routed.

Fig 3: Identifying Rear Side Steering Wheel Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Make sure shift paddles are correctly seated.

Make sure multifunction steering wheel switches are correctly seated.
