51 16 202 Removing And Installing/Replacing Front (Inner Or Outer) Cup Holder

Necessary preliminary work

• Remove COVER ON DASHBOARD  on right

Release the screws (1) and pull out the cup holder (2) in direction of arrow.

Replacement

REPLACE THE COVER OF THE SECOND CUP HOLDER .

Fig 1: Pulling Out Cup Holder

Courtesy of BMW OF NORTH AMERICA, INC.
