51 47... Removing and installing/replacing C-pillar storage compartment at bottom left or right

WARNING: This page is about a different car, the 2010 BMW X6. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Open rear door
Remove REAR ENTRANCE COVER STRIP
Remove LOWER C-PILLAR TRIM

Unclip rear seat towards rear.

Installation:

Feed seat belt buckles (1) into openings in rear seat.

Fig 1: Removing Rear Seat

Courtesy of BMW OF NORTH AMERICA, INC.

Detach mucket (1) in area of storage compartment (2).

Remove mat insert (3) from storage compartment (2) and release screws underneath (4).

Fig 2: Identifying Storage Compartment, Mucket, Mat Insert And Underneath Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Release clips (1).

Pull out storage compartment (2) in direction of arrow from clip (3).

Installation:

If necessary, release clips (2 and 3) from vehicle.

Install storage compartment (2) with preinstalled clips (1).

Fig 3: Identifying Storage Compartment And Mounting Clips

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Retainers (1) must not be damaged or missing.

If necessary, replace faulty clips (2).

Fit missing clips on storage compartment (3).

Fig 4: Identifying Storage Compartment, Retainers And Clips

Courtesy of BMW OF NORTH AMERICA, INC.
