0492639 513103 Gauge Mechanical tool

WARNING: This page is about a different variant/trim than selected.
NOTE: (Test gauge) For checking and adjusting the sheet metal angles on the window frame
Fig 1: Identifying Gauge (0492639)
G09835259Courtesy of BMW OF NORTH AMERICA, INC.
